Every wet crawl space in Sumner is a slow-motion disaster for the wood structure above it. Our heavy-duty vapor barrier systems stop ground moisture permanently.
What makes our encapsulation installs last decades, not years.
We install 20-mil reinforced polyethylene vapor barriers -- not the thin 6-mil sheeting that degrades within a few years under crawl space conditions.
Every seam in our vapor barrier installation is overlapped and taped with purpose-made crawl space seam tape rated for the temperature and humidity range your crawl space experiences.
HVAC equipment running in an encapsulated crawl space operates at higher efficiency because humidity does not overload the system's dehumidification capacity.
Protecting the wood structure of your home from moisture is the most cost-effective maintenance you can invest in, and crawl space encapsulation is the most efficient way to accomplish it.
The science behind crawl space encapsulation centers on moisture vapor transmission from exposed soil surfaces. Even dry-looking crawl space soil emits moisture vapor continuously at a rate that can introduce gallons of water per day into the air under your home. Traditional building practice placed foundation vents to exhaust this moisture, but research has repeatedly shown that venting in humid climates introduces more moisture than it removes, because the air flowing in from outside is often more humid than the air inside the crawl space. Sealing the crawl space and managing its humidity with a rated dehumidifier consistently outperforms venting in IL climates.
Seam treatment is what separates a professionally installed system from a DIY job that looks similar from a distance. Every seam in our installations is lapped a minimum of 12 inches and taped with a 4-inch crawl space tape rated for the temperature and humidity cycle of your crawl space. Penetrations for plumbing pipes, support columns, and structural posts are individually wrapped with additional barrier material and taped circumferentially so the junction between the pipe and the barrier is fully sealed. A barrier with unsealed seams can still allow significant moisture vapor migration because vapor follows the path of least resistance -- which is any gap, however small.
HVAC performance in homes with encapsulated crawl spaces improves because the humidity load on the air conditioning system is reduced. In a vented crawl space, humid outside air is drawn under the house, rises through the subfloor into the living space, and must be removed by the air conditioning system. This hidden moisture load causes air conditioners to run longer, increases compressor wear, and reduces the effective cooling capacity of the system. After encapsulation, the crawl space humidity is maintained by a rated standalone dehumidifier that handles only the manageable internal moisture load rather than an endless supply from outside air.
Crawl space dehumidification is the final element of a complete encapsulation system. Even a fully sealed crawl space generates some internal humidity from concrete foundation walls and the residual moisture in the soil, particularly in the first season after installation when the soil is transitioning to a lower equilibrium moisture content. A rated crawl space dehumidifier sized to the cubic footage of the space maintains interior relative humidity below the threshold that supports mold growth. We specify units with gravity drain or condensate pump to eliminate the manual emptying requirement, and we set the humidistat to an appropriate setpoint for Sumner, IL conditions before completing each project.
Six crawl space services that address every moisture source under your Sumner home.
20-mil reinforced poly barrier installed across the entire crawl space floor and up foundation walls, sealed at all seams and penetrations for complete moisture control.
Rated standalone crawl space dehumidifiers installed with gravity drain or condensate pump, sized to the cubic footage of your specific crawl space and set to maintain safe humidity levels year-round.
Existing foundation vents are sealed with rigid foam insulation cut to size and adhered with spray foam to eliminate the primary pathway for outside humid air to enter the crawl space.
Post-treatment borate preservative application inhibits future mold and decay fungi development on all treated wood surfaces under conditions of elevated humidity.
Drainage channels are integrated under the vapor barrier perimeter, routing water to a sump pit with a submersible pump sized for your drainage area.
We install weatherstripping and rigid foam panel inserts on all access points sized to provide an airtight fit that maintains the pressure balance of the sealed crawl space.
We enter the crawl space and conduct a systematic inspection of all floor and wall surfaces, document moisture meter readings at multiple locations, photograph all floor joist and beam conditions, and identify every source of water or moisture entry before recommending any course of action.
Where mold remediation is needed, we complete EPA-registered fungicidal treatment and borate application before any encapsulation materials are installed, ensuring no active mold is sealed under the barrier.
Foundation vents are sealed with rigid foam insulation and spray foam adhesive, and the crawl space access hatch is fitted with an insulating door seal panel.
We take final moisture readings and photograph the completed installation before issuing your written warranty documentation and maintenance schedule.
Our floor joists were showing early decay when JCB Waterproofing and Construction inspected. They remediated the mold, sealed the entire crawl space, and installed a dehumidifier -- a year later the wood moisture readings are in the safe range and the floors feel solid again.
The crew was thorough and professional. They explained what they found, showed me photos, and completed the work exactly as quoted. The crawl space is completely dry now and looks professionally done.
I got four quotes and JCB Waterproofing and Construction was the only company that gave me a written spec listing the mil thickness of the poly they were installing. That transparency is why I chose them and their work backed it up completely.
Get a written quote from our Sumner, IL encapsulation specialists -- no obligation, no pressure, just a clear plan.
